TECHNICAL DATA
Machinable Products | Ball chain / Rosary chain |
Max. diameter chain | 6 mm |
Number of working axes | 12 |
Axis tilt Table | -20° / +45° |
Axis tilt Tool Heads | -45° / +180° |
Dragging And Spool Unit | |
Spool dimensions | Øe.150 / Øi.45 x L.i.74 mm |
Feed speed | from 0 to 3.5 m/min |
Vertical Head | |
Tool rotation speed | from 0 to 20000 rpm |
Tool pincer diameter | 6 mm |
Horizontal Head | |
Tool rotation speed | from 0 to 15000 rpm |
Tool diameter | 80 mm |
Installation Data | |
Wattage | 5 kW |
Power supply | 400 V, 50/60 Hz, 3~ |
Pneumatic supply | 6 bar |
Weight | 1000 kg |
