RA 2700

RA 2700

DIAMOND CUTTING MACHINE FOR MULTICUTTING ON CHAINS

Patented RA 2700 Diamond Cutting Machine, with four horizontal heads, suitable to get multiple faceting and shaping on various kind of chains in one pass only



DOWNLOAD TECHNICAL DATASHEET

WATCH ON YOUTUBE

SKU: RA-2700 Category: Product ID: 2351

Description

TECHNICAL DATA

Machinable Products Cable/Square chains
Number of working axes 4 (Dragging and vice discs unit/Tool)
Dragging Unit
Feed speed from 0 to 4 m/min
Vice Discs Unit
Pin diameter 20 mm
Depth adjustment from -5 to +5 mm
Centring adjustment from -5 to +5 mm
Horizontal Head
Speed 7500 rpm
Tool holder diameter 100 mm
Installation Data
Wattage 3,5 kW
Power supply 400 V, 50/60 Hz, 3~
Weight 520 kg
